框架液压机适用于三聚氰胺门皮,天然木皮门皮的模压贴面成型,压机采用弹簧式同步闭合机构,可根据生产工艺在任何位置停止(即限位控制),且停留时间可调,減少了最低层和最高层受压时间差,好的保证产品的质量。其保压时间以及压力设定好之后可自动控制,压贴可以采用一次压贝占成型或者两次压贴成型,后者的效果要好一点。Door skin hot press is suitable for melamine door skin, natural veneer door skin. The synchronizer ishuman oriented design which let the hot platens can be stopped at any position (i.e. limit control),and theresidence time is adjustable, it can reduce the compress ion time difference between the lowest layer andtop layer, so that, it can better ensure product quality. The time of the pressure and the pressure value canbe automatically set&controlled
型号/Type | 总压力/Total pressure(KN) | 油缸直径/Diameter of the main oil cylind(mm) | 油缸数量/Quantity of the main oil cylind | 幅面尺寸/size |
SBYJ -DS700 | 7000 | Φ280 | 6 | 3'*7'、4'*8' or customized |
SBYJ -DS900 | 9000 | Φ280 | 6 | 3'*7'、4'*8' or customized |
SBYJ -DS1200 | 12000 | Φ320 | 6 | 3'*7'、4'*8' or customized |
SBYJ -DS1400 | 14000 | Φ340 | 8 | 3'*7'、4'*8' or customized |
